Мукопросеиватель СЭМЗ Ш2-ХМВ-03 без циклона и рамы

Mucoperiostal SEMP W2-HMV-03 is used in the baking industry for the controlled continuous sifting of the flour of wheat and rye varieties. The equipment consists of separator, and electric drive motor. The model is equipped with rare earth magnets, service life is 12 years since the release of mucoproteins.

The supply of flour is due to the use of pneumatic transport, then the flour is transferred via a screw conveyor into the sieve. The screw is made with a variable step to education in it flour tube, preventing the ingress of air from the delivery system into the sifter. At the output of mucoproteins installed magnets that catch metal particles. Waste outlet is through the pipe, to which you can attach bag to collect waste.

In the delivery set includes a mesh of carbon steel with a cell size of 3 mm. On request, the sieve and the material can be changed, and the type of sieves on a sheet of expanded metal.

The equipment is similar to the qualitative equipment and ingredients from Borat VM-6A and Voronezh-2.

Features:

• Capacity: up to 6000 kg/h*
• Screen area: 0,54 m2
• Possible mesh: 2-4 mm
• Installed drive power: 1.1 kW
• Dimensions: mm HH
• Weight: 190 kg

* Performance depends on the size of the mesh cell, the type of screen, variety of flour and its moisture content.
